12.8V 300Ah Powerful Electric Car Battery Pack High Efficient Charge

    Buy cheap 12.8V 300Ah Powerful Electric Car Battery Pack High Efficient Charge from wholesalers

    Buy cheap 12.8V 300Ah Powerful Electric Car Battery Pack High Efficient Charge from wholesalers
    • Buy cheap 12.8V 300Ah Powerful Electric Car Battery Pack High Efficient Charge from wholesalers

    12.8V 300Ah Powerful Electric Car Battery Pack High Efficient Charge

    Ask Lasest Price
    Brand Name : HRESYS
    Model Number : VHR VDA13450LFP
    Certification : CE/UL
    Price : Negotiable
    Delivery Time : 30 DAYS
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 1800000 PCS/YEAR
    • Product Details
    • Company Profile

    12.8V 300Ah Powerful Electric Car Battery Pack High Efficient Charge

    1.12.8V 300Ah LITHIUM ION(LFP) electrical vehicles BATTERY Module W: 423.5mm X D: 177.5mm X H: 203.0mm


    • Product Features

    · Safety: 12V 450Ah deep cycle lithium ion battery, built-in BMS, none fire, none explosive

    · Clean and Green energy, no toxic material contained

    · Powerful: By China 2C rate cell

    · Long life cycle: after 3000 cycles, there is 85% remaining capacity

    · No memory effect,highly efficient charge anytime, no reduction of capacity

    · Operation temperature: -20~60°C

    · Good performance at high temperature and high temperature resistance

    · Low self-discharge rate

    · High energy density cells with good performance.


    • Product Specification​
    ItemSpecificationRemarks
    Nominal Capacity450AhStandard discharge (1) capacity after standard charge (2)
    Actual Capacity465AhActual testing results according to the Standard discharge
    Nominal Voltage12.8VConfiguration: 4S3P - VHR 32173184LFP-150Ah. Voltage of single cell is 3.2V.
    Voltage at End of Charge14.4V@ 25 ± 3℃
    Voltage at End of Discharge10.4V@ 25 ± 3℃
    Nominal Continuous Charge Current (CC Threshold)150A@ 25 ± 3℃
    Nominal Continuous250A@ 25 ± 3℃
    Discharge Current
    Maximum Continuous Charge Current (CC Threshold)225A@ 25 ± 3℃
    Peak-Charge (50%SOC 10s)350A@ 25 ± 3℃
    Charge Voltage-cell3.60V/cellN.A.
    Maximum Continuous450A@ 25 ± 3℃
    Discharge Current
    Peak-Discharge (50%SOC 10s)500A@ 25 ± 3℃
    Voltage at End of Discharge-cell2.60V/cell 0℃~60℃N.A.
    2.50V/cell -20℃~0℃
    Operation AllowableCharge: 0~60°CN.A.
    Temperature RangeDischarge: -20~60°CN.A.
    Continuous Discharge Power1.92KW50%SOC
    Continuous Charge Power0.8KWN.A
    Self-discharge Rate/Month≤4%@ 25 ± 3℃,50%SOC
    Cycle Life(cycles)≥5000@ 25 ± 3℃,0.2C/0.5C @80%DOD
    Operation Allowable≤95% RHOperation
    Humidity Range≤85% RHStorage
    Recommended0~40°CMax. 6 month
    Storage temperature
    Weight43(±2)kgN.A.

    • Dimension
    Model No.Nominal VoltageNominal CapacityActualDimensionWeightMaterialWelding Manner
    Capacity(W X D X H, mm)
    VHR VDA13450LFP12.8V450Ah465AhWidth:579.5mm (±2)43(±2)kgAluminumLaser welding
    Depth: 177.3mm (±2)
    Height: 203.0mm (±2)

    12.8V 300Ah Powerful Electric Car Battery Pack High Efficient Charge


    • Application

    12.8V 300Ah Powerful Electric Car Battery Pack High Efficient Charge12.8V 300Ah Powerful Electric Car Battery Pack High Efficient Charge
