12V 200AH UPS Lead Acid Battery Reliability Safety High Efficient Charging

    Buy cheap 12V 200AH UPS Lead Acid Battery Reliability Safety High Efficient Charging from wholesalers

    Buy cheap 12V 200AH UPS Lead Acid Battery Reliability Safety High Efficient Charging from wholesalers
    • Buy cheap 12V 200AH UPS Lead Acid Battery Reliability Safety High Efficient Charging from wholesalers

    12V 200AH UPS Lead Acid Battery Reliability Safety High Efficient Charging

    Ask Lasest Price
    Brand Name : HRESYS
    Model Number : VHR 12DT200
    Certification : CE
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 1800000 PCS/YEAR
    Delivery Time : 30 DAYS
    • Product Details
    • Company Profile

    12V 200AH UPS Lead Acid Battery Reliability Safety High Efficient Charging

    12V 250AH Duration Top Terminal Lead-acid Batteries for CATV, L520mm x W268mm x H220mm


    • Product Overview

    HRESYS DT Series Duration Top Terminal Valve Regulated Lead Acid Battery is specially designed for UPS

    Applications including telecom, UPS, IDC, security and alarm system, utilities, emergency light systems, CATV and other backup applications.

    With corrosion resistance thick grid, international leading technologies and State-of-the-art automated manufacturing, DT series offer long cycle life, large current discharge capability, high consistency reliability and safety, and environmental-friendly.​


    • Features and Benefits​

    - Multi-purpose Application: The battery can be floating application as well as cyclic application

    - Low Self-discharge: Adopted high quality grid alloy and high purity electrolyte, low self-discharge

    - High Reliability and Safety: Adopted enhanced ABS container and special design safety valve to ensure battery high durable, safe and reliable


    • Product Specification​

    Nominal Voltage (V)12
    Nominal Capacity (25 C)200 Ah@C10 (to 1.80Vpc)
    Dimension (mm)L522mm x W240mm x H220mm
    Approx. Weight60.0kg (132.3 lbs.)
    Terminal TypeFemale Copper Insert M8
    Internal ResistanceApprox. 0.003 Ohm (fully charged@ 20°C)
    Max. Charge Current50 A
    Self-DischargeApprox. 3% per month @ 25°C
    Ambient Temperature

    Discharge: -20~55°C

    Charge: -20~50 °C

    Storage: -20~45°C

    Float Charge Voltage13.6V/block @25℃
    Equalize Charge Voltage14.4V/block @25℃
    Container MaterialABS (UL94-V0 optional)

    • Applications

    o Outdoor telecom

    o UPS

    o IDC

    o Security and alarm system

    o Utilities

    o Emergency light systems

    o CATV


    • Complied standards

    o IEC 6 - 1056-1

    o GB/T 22199

    o GB/T 19639-1

    o JIS C870 - 2 1


    • Management and Product Certificates

    o ISO9001:2015

    o ISO14001:2015

    o OHSAS18001:2007

    o CE Certificate


    • Battery Dimension


    • Performance Curves

    · Cyclic Characteristics

    High cycle performance: up to 550 cycle at 80%DOD


    12 V 120 AH Superior Cycle Gel Lead-acid Batteries for Cyclic Applications with Frequent Cycles, L405mm x W174mm x H232m
