120AH High Output Motorcycle Battery Wide Temperature Range Extremely Safe

    Buy cheap 120AH High Output Motorcycle Battery Wide Temperature Range Extremely Safe from wholesalers

    Buy cheap 120AH High Output Motorcycle Battery Wide Temperature Range Extremely Safe from wholesalers
    • Buy cheap 120AH High Output Motorcycle Battery Wide Temperature Range Extremely Safe from wholesalers

    120AH High Output Motorcycle Battery Wide Temperature Range Extremely Safe

    Ask Lasest Price
    Brand Name : HRESYS
    Model Number : VHR ES12120LFP
    Certification : CE/UL
    Price : Negotiable
    Delivery Time : 30 DAYS
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 1800000 PCS/YEAR
    • Product Details
    • Company Profile

    120AH High Output Motorcycle Battery Wide Temperature Range Extremely Safe

    120AH High Capacity/ long cycle life Lifepo4 UPS/golf cart Lithium Ion Battery Pack


    • Superior Character

    1, Broad operating temperature range: discharge temperature: -20-60°c

    2, High capability and stability.

    3, Low self-discharge and fast charge

    4,. Good safety performance:When the pressure inside the battery is too large, the one-way safety valve will release gas and heat to make sure battery perform well. When the internal pressure reaches a certain level, the valve will be open immediately which can protect the battery from burning and explosion.

    5, High Safety Ensured by Smart BMS.

    6, High Energy Density by Adopting LFP Cells

    7, Environmentally friendly and free from heavy metal.


    • Application

    For example

    120AH High Output Motorcycle Battery Wide Temperature Range Extremely Safe120AH High Output Motorcycle Battery Wide Temperature Range Extremely Safe


    • Product Specification​
    Electrical Characteristics
    Nominal Voltage12.8V
    Nominal Capacity@0.2C120Ah
    Energy1536Wh
    Internal Resistance≤45m Ω
    Cycle Life≥3000 Cycles
    Months Self Discharge≤3.5% per month at 25℃
    Mechanical
    Cell & MethodIFR32700 N60, 15S20P
    Plastic CaseABS
    Dimension(L × W × H × TH)409 × 177 × 224 × 224mm
    WeightApprox. 14.6Kg
    TerminalM8
    Standard Charge
    Charge Voltage14.6 ± 0.2V
    Charge Mode(CC/CVAt 0℃~45℃ temperature, charged to 14.6V at a constant current of
    0.2C, and then charged continuously with constant voltage of
    14.6V until the current was not more than 0.02C.
    Charge Current24A
    Max. Charge Current60A
    Standard Discharge
    Discharge Current24A
    Max. Continuous Current100A
    Max. Pulse Current200A(<3S)
    Discharge Cut-off Voltage10.0V
    Operating Environment
    Charge Temperature0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity
    Discharge Temperature—20℃ to 60℃(-4℉ to 140℉) @60±25% Relative Humidity
    Storage Temperature0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity
    Water Dust ResistanceIP55
    Protection Parameter
    Over-current Protection Current300A
    Over-charge Protection Voltage15.2V
    Over-discharge Protection Voltage9.2V
    High Temperature Protection65℃

    • Different DOD Discharge Cycle Life Curve

    Different DOD Discharge Cycle Life Curve @0.5C, 25 ℃

    120AH High Output Motorcycle Battery Wide Temperature Range Extremely Safe
