150AH Lithium Ion Motorcycle Battery With Short Circuit Production Function

    Buy cheap 150AH Lithium Ion Motorcycle Battery With Short Circuit Production Function from wholesalers

    Buy cheap 150AH Lithium Ion Motorcycle Battery With Short Circuit Production Function from wholesalers
    • Buy cheap 150AH Lithium Ion Motorcycle Battery With Short Circuit Production Function from wholesalers

    150AH Lithium Ion Motorcycle Battery With Short Circuit Production Function

    Ask Lasest Price
    Brand Name : HRESYS
    Model Number : VHR ES12150LFP
    Certification : CE/UL
    Price : Negotiable
    Delivery Time : 30 DAYS
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 1800000 PCS/YEAR
    • Product Details
    • Company Profile

    150AH Lithium Ion Motorcycle Battery With Short Circuit Production Function

    150AH High Capacity/ long cycle life Lifepo4 UPS/golf cart Lithium Ion Battery Pack


    • Superior Character

    1, The capacity, resistance, voltage, platform time can maintain good consistency

    2, very safe and reliable because of the short-circuit production function.

    3, Super Long Service Life

    4, High Energy Density by Adopting LFP Cells.

    5, High Safety Ensured by Smart BMS.

    6, Adaptability to a wide range of temperature: the battery can work at temperature between -20℃ and +65℃.


    • Application

    Electric vehicle
    Golf cart
    Electric motorcycle
    Electric boat
    Electric forklift
    Telecommunication
    Distributed Grid Energy Storage system
    Mining equipment
    Solar energy storage system
    Marine
    Backup power
    Household energy storage system


    For example:

    150AH Lithium Ion Motorcycle Battery With Short Circuit Production Function150AH Lithium Ion Motorcycle Battery With Short Circuit Production Function


    • Product Specification​
    Electrical Characteristics
    Nominal Voltage12.8V
    Nominal Capacity@0.2C120Ah
    Energy1536Wh
    Internal Resistance≤45m Ω
    Cycle Life≥3000 Cycles
    Months Self Discharge≤3.5% per month at 25℃
    Mechanical
    Cell & MethodIFR32700 N60, 15S20P
    Plastic CaseABS
    Dimension(L × W × H × TH)409 × 177 × 224 × 224mm
    WeightApprox. 14.6Kg
    TerminalM8
    Standard Charge
    Charge Voltage14.6 ± 0.2V
    Charge Mode(CC/CVAt 0℃~45℃ temperature, charged to 14.6V at a constant current of
    0.2C, and then charged continuously with constant voltage of
    14.6V until the current was not more than 0.02C.
    Charge Current24A
    Max. Charge Current60A
    Standard Discharge
    Discharge Current24A
    Max. Continuous Current100A
    Max. Pulse Current200A(<3S)
    Discharge Cut-off Voltage10.0V
    Operating Environment
    Charge Temperature0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity
    Discharge Temperature—20℃ to 60℃(-4℉ to 140℉) @60±25% Relative Humidity
    Storage Temperature0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity
    Water Dust ResistanceIP55
    Protection Parameter
    Over-current Protection Current300A
    Over-charge Protection Voltage15.2V
    Over-discharge Protection Voltage9.2V
    High Temperature Protection65℃

    • Charge Characteristics

    Charge Characteristics @0.2C&0.5C, 25
