12 V 20 AH VRLA Gel EV Battery Pack 6-DZM-20 With Reliable Seal Structure

    Buy cheap 12 V 20 AH VRLA Gel EV Battery Pack 6-DZM-20 With Reliable Seal Structure from wholesalers

    Buy cheap 12 V 20 AH VRLA Gel EV Battery Pack 6-DZM-20 With Reliable Seal Structure from wholesalers
    • Buy cheap 12 V 20 AH VRLA Gel EV Battery Pack 6-DZM-20 With Reliable Seal Structure from wholesalers
    • Buy cheap 12 V 20 AH VRLA Gel EV Battery Pack 6-DZM-20 With Reliable Seal Structure from wholesalers
    • Buy cheap 12 V 20 AH VRLA Gel EV Battery Pack 6-DZM-20 With Reliable Seal Structure from wholesalers

    12 V 20 AH VRLA Gel EV Battery Pack 6-DZM-20 With Reliable Seal Structure

    Ask Lasest Price
    Brand Name : HRESYS
    Model Number : 6-DZM-20
    Certification : CE
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 1800000 PCS/YEAR
    Delivery Time : 30 DAYS
    • Product Details
    • Company Profile

    12 V 20 AH VRLA Gel EV Battery Pack 6-DZM-20 With Reliable Seal Structure

    12 V 20 AH VRLA Gel Battery for motive power applications, 6-DZM-20, L180mm x W76mm x H170mm


    • Product Overview

    HRESYS DZM series VRLA Gel Battery provides efficient and sustainable vehicle operations with minimal running costs over a long, low-maintenance service life. They are clean and safe, making them ideal for use in golf cars, personnel carriers, and floor scrubbers / sweepers, where acid leaks could damage floors, walkways and carpeting. They are also well suited for alternative energy sources, such as photovoltaics. HRESYS DZM series adopts advanced technology to ensure the batteries with features of long cycle life, lower discharge, high reliability and safety, and environmental-friendly.


    • Features and Benefits​

    • Long Cycle Life: Exceptional cyclic performance above 600 cycles @80% DoD.
    • Reliable Seal Structure: Mount in any position except inverted
    • Optimal Design: Besides the benefits of VRLA battery, it is maintainable that can prolong the service life by up to 50%-100% or more.
    • Multi-purpose Application: The battery can be floating application as well as cyclic application.
    • Critical pressure control valve for longer battery life
    • Gelled electrolyte is completely leakproof and spillproof for easy installation in virtually anp position
    • Forged terminal posts and bushings
    • Brushed plate lugs to eliminate dropped and loose plates that reduce performance and shorten battery life

    • Applications

    • Electric Bike / Scooters
    • Electric Tricycles
    • Electric Tools and Toys
    • Mini Solar Power System

    • Product Specification​

    Nominal Voltage (V)12V (6 cells per unit)
    Nominal Capacity (25 C)20 Ah @ 2 -rate (to 1.75Vpc)
    Dimension (mm)L180mm x W76mm x H170mm
    Approx. Weight6.6 kg (14.55 lbs)
    Terminal TypeFemale Copper Insert M5
    Internal Resistance≤ 0.01 Ohm (fully charged)
    Initial Charge Current≤3.0A
    Self DischargeApprox. 2.0% per month @ 20°C
    Ambient TemperatureDischarge: -20~55°C
    Charge: -20~45 °C
    Storage: -20~45°C
    Float Charge Voltage13.5~13.8V/block @25 C
    Сycle Use Charge Voltage14.7~14.9V/block @25 C
    Container MaterialABS (UL94-V0 optional)

    • Complied standards

    • IEC 61056-1
    • GB/T 22199
    • JIS C8702-1
    • GB/T 19639-1


    • Management and Product Certificates

    • ISO9001:2015
    • ISO14001:2015
    • OHSAS18001:2007
    • CE Certificate

    • Battery Dimension


    • CHARACTERISTICS

    • Typical Application
