    12 V 26 AH Top Terminal VRLA AGM Battery for General Purpose , L175mm x W166mm x H125mm

    Ask Lasest Price
    Brand Name : HRESYS
    Model Number : VHR 12GT26
    Certification : CE
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 1800000 PCS/YEAR
    Delivery Time : 30 DAYS
    • Product Details
    • Company Profile

    12 V 26 AH Top Terminal VRLA AGM Battery for General Purpose , L175mm x W166mm x H125mm

    12 V 26 AH Top Terminal VRLA AGM Battery for General Purpose , L175mm x W166mm x H125mm


    • Product Overview

    HRESYS VRLA Gel battery GT series has high energy density and high reliability performance which is because of its advanced design technology and manufacturing technique and industry scale. GT series is designed for UPS systems, security and alarm systems, telecommunication, utilities, emergency light systems, and other backup applications.


    • Features and Benefits​
    1. Valve Regulated Lead Acid AGM technology
    2. Standard sizes for general purpose
    3. Flexible design for multiple installation space
    4. Low self-discharge rate
    5. Maintenance free by valve regulated
    6. 12V series available from 7Ah to 250Ah
    7. 5+ years design floating life at 25°C (77°F)

    • Applications
    1. Uninterrupted Power Supply(UPS)
    2. Emergency Power Supply
    3. Electric Tools and Toys
    4. Cable Television

    • Working Scenarios
    1. Batteries are mainly working as backup power with not many cycles
    2. Backup time normally doesn’t exceed 2 hours
    3. Shadow cyclic use and cycles not many

    12 V 26 AH Top Terminal VRLA AGM Battery for General Purpose , L175mm x W166mm x H125mm


    • Product Specification
    Nominal Voltage (V)12
    Designed Floating Life (25℃)5 Years
    Nominal Capacity (25℃)26 Ah@ C20 (to 1.75Vpc)
    Dimension (mm)L175mm x W166mm x H125mm
    Approx. Weight8.15 kg (18.0 lbs)
    Terminal TypeFemale Copper Insert M5
    Internal Resistance≤ 0.010m Ohm (fully charged @25℃)
    Max. Charge Current7.2 A
    Max. Discharge Current(5S)310 A
    Short Circuit Current1000 A
    Self DischargeApprox. 2.5% per month @ 20℃
    Ambient TemperatureDischarge: -20~55℃
    Charge: -20~50℃
    Storage: -20~45℃
    Float Charge Voltage13.6V @25℃
    Equalize Charge Voltage14.4V @25℃
    Container MaterialABS (UL94-V0 optional)

    • Complied standards

    o IEC 60896-21/22

    o GB/T 19638

    o IEC61427

    o JIS C8704

    o BS6290 PART4


    • Management and Product Certificates

    o ISO9001:2015

    o ISO14001:2015

    o OHSAS18001:2007

    o CE Certificate


    • Battery Dimension

    12 V 26 AH Top Terminal VRLA AGM Battery for General Purpose , L175mm x W166mm x H125mm


    • Performance Curves

    12 V 26 AH Top Terminal VRLA AGM Battery for General Purpose , L175mm x W166mm x H125mm
