125AH Telecom Battery Long Life 12 Floating Charging Conditions 12 V

    Buy cheap 125AH Telecom Battery Long Life 12 Floating Charging Conditions 12 V from wholesalers

    Buy cheap 125AH Telecom Battery Long Life 12 Floating Charging Conditions 12 V from wholesalers
    • Buy cheap 125AH Telecom Battery Long Life 12 Floating Charging Conditions 12 V from wholesalers

    125AH Telecom Battery Long Life 12 Floating Charging Conditions 12 V

    Ask Lasest Price
    Model Number : 12DF125
    Price : Negotiable
    Delivery Time : 30 DAYS
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 1800000 PCS/YEAR
    • Product Details
    • Company Profile

    125AH Telecom Battery Long Life 12 Floating Charging Conditions 12 V

    • 12 V 125AH Lead-acid Batteries with Long Life of 12 Floating Charging Conditions,L558mm x W112mm x H295mm
    • Product Overview

    The HRESYS DF (Duration Front) series VRLA batteries is especially designed for telecommunication

    with 12+ years float design life. By combining the newly developed paste formula with up-to-date AGM

    structures, the series meet latest IEC, British and Telcordia standards. Front Access connection and

    centralized venting system of DF series for fast, safety installation and maintenance.

    • Features and Benefits​

    Long life
    -4BS paste technology
    - Special paste prescription
    -Special patent grid alloy
    -Thick plate design
    Reliable seal performance, no acid spillage to cause equipment erosion.
    - Reliable seal performance, recombination efficiency reach 99%
    -Post sealing structure
    -Whole valve design ensure the precision
    Excellent high rate discharge performance
    -Cross-wall welding between each cell, this construction made internal resistance very low
    -Superior grid radiates style design; raise the high rate discharge performance.
    -Special paste technology
    -Copper core cable, copper bar as optional


    • Applications


    • Complied standards

    -IEC 60896-21/22

    -GB/T19638

    -YD/T 799

    -JIS C8704

    -BS6290 part 4

    • Product Specification​
    Nominal Voltage (V)12 (6 cells per unit)
    Nominal Capacity (25 C)125 Ah @ 10HR-rate (to 1.80Vpc)
    Dimension (mm)L558mm x W112mm x H295mm
    Approx. Weight42.3kg (93.2 lbs)
    Terminal TypeFemale Copper Insert M8 (torque: 10~12N.m)
    Internal ResistanceApprox. 0.0058 Ohm (fully charged)
    Max. Charge Current31 A
    Max. Discharge Current (5S)850 A
    Short Circuit Current2000 A
    Self DischargeApprox. 2.5% per month @ 20℃
    Ambient TemperatureDischarge: -20~60℃
    Charge: -20~55℃
    Storage: -20~45℃
    Float Charge Voltage13.5V/block @25℃(-3mV/ cell/ C)
    Сycle Use Charge Voltage14.1V/block @25℃
    Container MaterialABS UL ( 94-V0 optional)

    • Battery Dimension


    • Performance Curves


    • Factory Overview
